Mortsie Lock Single Point Active 60mm Backset Marvin, Caradco, Jeldwen doors
We are an Authorized Distributor for Andersen, Larson, Marvin, Pella, GU Ferco, Hoppe, Emtek, Roto, Milgard, Peachtree, Weathershield, and many more. Shop our store for your door and window hardware needs. Customer Service Hours Monday-Friday 8am-4pm CST Single point active lock (SPL) for Marvin Ultimate and other inswing doorsmanufactured 1/17/2000 to present.For mortise lock faceplate, see part # 395040Lock Body Type: American cylinderHandle spacing: 3-5/8 inch (92 mm) Center of handle to center of cylinderBackset: 2-3/8 inch (60 mm) Measured from door edge to center of handleBackset without Face plate (measures 2-5/16 as shown in 2nd image)Deadbolt throw: 1 inch (25.4 mm) TaperedPatent NO. 6,209,931Single point locks used by Marvin, Caradco, Jeldwen and othersPriced and sold each.NOTE: Does Not include faceplate or Strike, lock body onlyScrew between Latch and Deadbolt is a # 6 Flat head, not includedChange Handing:1. Insert screw driver into slot behind latch2. Pull down on handing release, latch pops out3. Rotate latch and push back into lock caseALWAYS Check Function of lock before closing doorOperation:1. Lift handle to engage2. Turn Thumbturn or key to extend the deadbolt
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Color | Silver |
| MPN | Does not apply |
| Material | Stainless Steel |
| Suitable For | Entire Door |
| Brand | Ashland |
| Mounting | Center Mount |
| Type | Mortise Lock |
| Door Handing | Universal/Reversible |
| Style | Modern |
| Features | Easy to Install |
| Finish | Polished |
