NEW BLUM 100-degree Full Overlay Modul Hinge, 70.255 w/ plate 193L610-01.02
This sale is for one (1) New Blum 100° Modul, Self-Closing, Full Overlay Hinge and 193L610-01.02 Mounting Plate. These come in sealed packages by Richelieu. Hinge can be used with any of the Blum Modul (Screw-on) Plates. Identifying marks on hinge: "70.255" ..."Blum"... "90M210-02.01" Please note that these numbers changed a lot over the years...Basically, you will either have the more common straight-arm (3/4" overlay) or the half-cranked arm (about 3/8" overlay) or the Full-cranked Inset arm. Half-cranked arms were used on inset doors (with a 9mm thick plate) or twin door applications, where you have back-to-back doors on a partition (not done on face frame applications). Cranked-arms are also taller and have a curve compared to straight-arm...This sale is for the full overlay straight arm hinge. Please note: the cup numbers "90.255, 80.255 and 70.255" all interchange, function and are the same. Photo 5 shows the difference in the 3 hinges (Full Overlay, Half-Overlay and Inset). It is your responsibility to determine if this hinge will work for your installation! If you have questions, please contact me. Technical info: Hinge bores use a 35 mm bit drilled 1/2" deep. An order consists of one hinge, 1 mounting plate and screws, but order as many as you like or need. Your order will go out in a USPS Flat-Rate Box or Ground Advantage Padded Envelope (2-5 day delivery) to anywhere the US Post Office will deliver. This includes Alaska, Hawaii, Puerto Rico and other US Territories. Can also ship overseas via International Shipping Center. Additional fees may apply to international orders. Please contact me with any questions or before leaving poor feedback. Thanks for looking! Depending on the item, we generally send out packages the next day after purchase (about 95% of items sold). We list "5-day handling" time for the larger items or items located in our storage facility. </font
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Brand | Blum |
| Type | Full Overlay |
| Color | nickel silver |
| Material | Steel |
| MPN | 70.255,193L610-01-02 |
| Features | Self Closing |
| Country/Region Of Manufacture | Austria |
| Finish | Nickel Plated |
| Suitable For | Cabinet Doors |
This sale is for one (1) New Blum 100° Modul, Self-Closing, Full Overlay Hinge and 193L610-01.02 Mounting Plate. These come in sealed packages by Richelieu. Hinge can be used with any of the Blum Modul (Screw-on) Plates. Identifying marks on hinge: “70.255” …”Blum”… “90M210-02.01″ Please note that these numbers changed a lot over the years…Basically, you will either have the more common straight-arm (3/4″ overlay) or the half-cranked arm (about 3/8” overlay) or the Full-cranked Inset arm. Half-cranked arms were used on inset doors (with a 9mm thick plate) or twin door applications, where you have back-to-back doors on a partition (not done on face frame applications). Cranked-arms are also taller and have a curve compared to straight-arm…This sale is for the full overlay straight arm hinge. Please note: the cup numbers “90.255, 80.255 and 70.255″ all interchange, function and are the same. Photo 5 shows the difference in the 3 hinges (Full Overlay, Half-Overlay and Inset). It is your responsibility to determine if this hinge will work for your installation! If you have questions, please contact me. Technical info: Hinge bores use a 35 mm bit drilled 1/2” deep. An order consists of one hinge, 1 mounting plate and screws, but order as many as you like or need. Your order will go out in a USPS Flat-Rate Box or Ground Advantage Padded Envelope (2-5 day delivery) to anywhere the US Post Office will deliver. This includes Alaska, Hawaii, Puerto Rico and other US Territories. Can also ship overseas via International Shipping Center. Additional fees may apply to international orders. Please contact me with any questions or before leaving poor feedback. Thanks for looking! Depending on the item, we generally send out packages the next day after purchase (about 95% of items sold). We list “5-day handling” time for the larger items or items located in our storage facility. </font
